This pipe hydro testing machine is mainly used for hydrostatic pressure testing of steel, plastic and composite pipelines, ensuring they meet strength and leak‑tightness requirements before use. It adopts reliable sealing methods such as end face sealing and radial expansion sealing to achieve high‑precision pressure closure. The end sealing components are designed for quick installation and robust sealing performance, allowing water pressure tests to reach specified levels with excellent accuracy. The radial sealing design enables testing across a wider range of pipe diameters and provides more uniform stress distribution during pressurization.
Equipped with an advanced PLC control system and real‑time pressure monitoring, the pipe hydro testing machine supports functions such as automatic pressure ramping, pressure holding, pressure release, and test result recording. Visual intelligent detection and data logging improve test traceability and quality documentation. Additional features include automatic sorting of failed products, alarm notifications on abnormal conditions, and remote network connectivity for centralized monitoring and management, significantly increasing testing efficiency and operational safety.
| Name | Model | Caliber range(mm) | Polishing length/m | Station | Teat pressure | Sealing method | Loading | Off loading | Capabilities |
| pipe hydrotest machine | ZYSY-25 | φ10-φ25 | 1-30 | 3-5 | 1.5Mpa | End face seal | Semi-automatic | Lossless off loading | Automatic sorting,remote networking |
| pipe hydrotest machine | ZYSY-63 | φ15-φ63 | 1-30 | 3-5 | 1.5Mpa | End face seal | Semi-automatic/Automatic | Lossless off loading | Automatic sorting,remote networking |
| pipe hydrotest machine | ZYSY-100 | φ51-φ114 | 2-40 | 3 | 1.5Mpa | End face seal | Semi-automatic/Automatic | Lossless off loading | Automatic sorting,remote networking |
| pipe hydrotest machine | ZYSY-114 | φ15-φ114 | 2-40 | 3 | 1.5Mpa | End face sea | Semi-automatic/Automatic | Lossless off loading | Automatic sorting,remote networking |
| pipe hydrotest machine | ZYSJ-50 | φ6-φ50 | 2-20 | 3-5 | 3.0Mpa | Radial seal | Semi-automatic | Lossless off loading | Automatic sorting,remote networking |
