The tube straightening machine is specifically designed for straightening precision tubes with tight tolerance requirements. It ensures smooth surfaces and accurate alignment while maintaining tube integrity.
Key Features
-
High-precision straightening rollers
-
Low surface damage during processing
-
Adjustable for various tube diameters
-
Continuous and stable operation
Applications
-
Precision mechanical tubes
-
Hydraulic and pneumatic tubing
-
Stainless steel and alloy steel tubes
Advantages
-
Maintains tube roundness
-
Improves dimensional accuracy
-
Suitable for high-precision tube manufacturing
Technical parameter table structure
| Parameter | Specification |
|---|---|
| Model | TSM-80 / TSM-125 |
| Applicable Tube OD | Φ5–Φ125 mm |
| Tube Wall Thickness | 0.5–8 mm |
| Straightening Speed | 10–50 m/min |
| Roller Material | Alloy steel / Carbide treated |
| Yield Limit | ≤490 MPa |
| Straightness Tolerance | ≤0.8 mm/m |
| Motor Power | 2–20 kW |
| Control | Manual / Electric / |
| Hydraulic | |
| Machine Weight | by model |
